BRAND | Vivoil Oleodinamica Vivolo |
Product | 010-180-01850-U / X1P2941DBBA |
Description | External gear pump |
Internal code | ONR4186485 |
Custom code | 84136031 |
Technical specification | Size 1 with aluminium body and aluminium lids Conveying volume: 4.94 ccm/rev Rotation direction: anti-clockwise Mounting flange: Fitting Ø 32 mm - 2 hole mounting 40 mm x 40 mm (mounting holes Ø 8.5 mm top right and bottom left) Drive Shaft: 5 mm flat shaft protruding Intake connection: G 3/8"” Pressure connection: G 3/8"” Installation length: 93.5 mm Sealing material: NBR Permissible shaft torque: 13.8 Nm Continuous pressure limited by drive shaft: 158 bar Permanent pressure: 250 bar Peak pressure (max. 0.5 sec): 290 bar Minimum speed: 700 rpm Maximum speed: 6000 rpm |
Please Contact Us to Order to offer competitive prices and delivery time for Vivoil Oleodinamica Vivolo - 010-180-01850-U / X1P2941DBBA External gear pump number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
