BRAND | Brilex |
Product | Nr. 1005-9318-00 Type KER/1000X1000 |
Description | explosion rupture disk |
Internal code | ONR4203291 |
Custom code | 73269098 |
Technical specification | Old Matno.: 2406336 Type: Fl. Bursting disc without counterpart Size: 1000X1000 Bursting area: 10,000 cm2 Option: default material: 1.4301 Opening pressure: 0.100 bar Opening temperature: 20.0 °C Opening pressure tolerance +/-: 0.010 bar Vacuum resistance: 500 mmWs Minimum temperature: -40.0 °C Maximum temperature: 120.0 °C Seal material: EPDM foam tape Insulation material type: None Grounding tab: no |
Please Contact Us to Order to offer competitive prices and delivery time for Brilex - Nr. 1005-9318-00 Type KER/1000X1000 explosion rupture disk number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
