BRAND | Burkert |
Product | 00069463 |
Description | 2/2-way solenoid valve |
Internal code | ONR4753162 |
Custom code | 84818079 |
Technical specification | servo-controlled 0290-A-20,0-FF-VA-GM85-024/UC-CC * CZ34+JH54+MT05+NL02 Type 0290 Mode of operation A 2/2-way; closed at rest Nominal diameter 20.0 20 mm FF FKM sealing material Material VA stainless steel GM85 G 3/4 socket cable connection Voltage 024 24 Volt Frequency UC direct and alternating current (AC/DC) Power consumption CC 100 watts suit, 9 watts operation Special feature CZ34 kick and drop coil with integrated temperature switch JH54 connector type 2518 (00314802), without circuit, 3-pin, 0-250 V AC/DC MT05 Direct coupling Pressure min 0 bar Pressure max 16 bar kV 6.50 m3/h QNN 7,000 l/min Medium temperature min 0 °C Medium temperature max 90 °C Ambient temperature max 55 °C |
Please Contact Us to Order to offer competitive prices and delivery time for Burkert - 00069463 2/2-way solenoid valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
