D-116  - Gutekunst United States  Sales

BRAND Gutekunst
Product D-116
Description Spring
Internal code ONR244576
Weight 0.001
Technical specification Type of material EN 10270-1 - Type of material Condition of Spring Ends Crushed and Ground - Condition of Spring Ends F1 N Force of the precompressed spring L1 mm Length of pre-compressed spring s1 mm Pre-compressed spring section F2N Compressed spring force L2 mm Compressed spring length s2 mm Compressed spring section d 0.7 mm Wire diameter Di mm Internal diameter of the coil D 6 mm Mean diameter of the coil Of 6.7 mm outer diameter of the spiral Dd 4.9 mm Maximum shaft diameter Dh 7.3 mm Minimum bushing diameter L0 35 mm Uncompressed spring length Lk 19.54 mm Length of deformation Fn 22,114 N Maximum force with static load Ln 11.57 mm Permissible length with static load sn 23.43 mm Maximum spring travel with static load Fndyn 21.28 N Maximum force with dynamic load Lndyn 12.45 mm Allowable length with dynamic load shdyn 5.79 mm Max spring travel under live load S 2.858 mm Spring pitch (distance from spiral center to spiral center) n 12 Units Number of elastic coils nt Units Total number of aspirations R 0.944 N/mm Stiffness index Gew 0.8028 g Item Weight Fntol 1.29 N (+/-) Maximum static force tolerance Fndtol 1.28 N (+/-) Dynamic maximum force tolerance Detol 0.25 mm (+/-) Turn diameter tolerance L0tol 1.01 mm (+/-) Uncompressed spring length tolerance PG B - Price group for this item F1tol N (+/-) Precompressed spring force tolerance F2tol N (+/-) Compressed spring force tolerance

Please Contact Us to Order to offer competitive prices and delivery time for Gutekunst - D-116 Spring number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
